Φ1600雙層臥式包帶機
Φ1600 double layer horizontal tapping machine
包帶機設備技術參數及性能介紹
Tapping machine technical parameters performance
用途 Application | 適用：銅線或線纜表面中心包帶用。如：銅帶、云母帶、 This machine can tapping the core wire wire surface with the copper belt, mica belt,aluminium foil,dion belt,the transparent belt,the wheat belt the adhesive-bond cloth. |
適用線徑 Suitable for wire diameter | MaxΦ40mm MaxΦ40mm |
適用包帶外徑 Suitable for belting bobbin outer diameter | Φ200mm-Φ550mm Φ200mm-Φ550mm |
適用盤徑 Suitable for the wire bobbin diameter | Φ1250mm-Φ1600mm Φ1250mm-Φ1600mm |
線盤裝卸 Bobbin loading unloading | 電動升降，氣壓夾緊 Electric lift , pneumatic clamp |
放線張力 Pay off tension | 10kg磁粉離合器控制 10kg magnetic powder clutch control |
繞包張力 Take up tension | 單軸磁粉剎車器控制 single axial magnetic powder brake control |
收線張力 Take up tension | 根據開圈直徑主動調整轉速，從空盤到滿盤收線張力保持一致 According to the open coil diameter to adjust the speed automatically,the tension keep consistent form the empty bobbin to the full bobbin |
馬達功率 Motor power | 三相380V、50Hz、繞包2.2kw、牽引5.5kw、收線5.5kw變頻調速 3 Phase,380V,50HZ,taping 2.2KW,traction 5.5KW,frequency conversion speed regulation |
包帶轉速 Taping rotate speed | 2000轉/分 2000rmp |
